Carboguard 890 is an epoxy mastic coating that is highly chemical resistant. This product offers a wide array of uses in various industrial sectors. Carboguard 890 is also suitable for self-priming and is ideal for use over surfaces with existing coatings or rust.
You can also use Carboguard 890 as a stand-alone system in various chemical and immersive environments. As per the product datasheet, if you wish to enhance the corrosion protection properties of the Carboguard 890, you can buy a micaceous iron oxide additive, also known as MIO fillers.
This procedure will also enhance the film strength for a prolonged and aggressive service in severe environments such as industrial or marine.
Features
Some of the most prominent features of the Carboguard 890 include:
- Tolerance against a variety of surfaces
- Exceptional chemical and corrosion resistance
- Self-priming finishing characteristics
- Low temperature and conventional versions
- Exceptional abrasion resistance
- VOC compliant with current AIM regulations
Applications
The applications include thick film cladding in the following industrial use:
- Oil and Gas Midstream
- Petrochemical
- Power-Conventional
Product Details
| Generic Type | Cycloaliphatic Anime Epoxy |
| Available Colors | It is available in a combination of more than 400 colors. However, the low-temperature formulation may cause discoloration of most colors or turn them yellow. For that reason, certain colors may require more than a single quote for hiding. |
| Finish | Gloss |
| Primer | Self Priming with approx 4 to 5 mils or 102 to 152 microns per coat |
| Dry Film Thickness | For uniform gloss finish over inorganic zinc: 6 to 8 mils or 150 to 200 micronsFor over light rust: 6 to 8 mils or 150 to 200 microns However, do not exceed the 10 mils or 250 microns mark for a single coat application. In the case of dealing with inorganic zinc, this can cause damage during use. |
| Solid Content | Volume 75% with a variation of up to 2% higher or lower |
Surface Preparation Chart
Here is a quick information on surface preparation for various surfaces
| Surface | Preparation |
| General Surface | The surface must be dry and clean. You must remove all residue or contaminate. |
| Surface preparation for steel | In the case of Steel Immersion: SSPC-SP6 1.5 to 3 mils, i.e., 38 to 75 microns SSPC SP2 or SSPC SP3, is suitable for cleaning under a mild environment. You can also use SSPC-SP10 non-immersion for the same. In the case of Galvanized Steel SSPC-SP 16: You must create 1.5 to 3 mils or 37.5 to 75 microns anchor profile |
| Surface Preparation for Concrete | You must design, place, cure, and prepare the concrete or CMU concrete. Prepare per NACE No. 6/SSPC-SP 13. This also involves abrading the surface to remove any loose concrete, laitance, etc. this is compulsory in order to create a surface profile ready for the coating system. Moreover, the concrete must also pass the moisture tests |
If you wish to read more details about the product and its applications, click here to read the PDS and SDS documents.
